IN-Q2M Biaxial inclinometer
Measures tilt along two coordinates. Used in structural monitoring systems with RS-485 data transmission.
Application
Application and connection
A precision tilt sensor for structural and geotechnical monitoring, including inclination and rotation over a wide angular range. Available in an IP68 stainless-steel housing or an aluminum housing.
The RS-485 / Modbus digital output allows up to 40 sensors on one measurement line over distances up to 800 m.
Parameters
Technical specifications
- Basic measurement error limit, % of span
- ±0.05%
- Polling rate
- Up to 50 readings/s
- Operating temperature range, digital models
- –50…+60 °C
- Ingress protection rating
- IP68
- Output interface
- RS-485
- Communication protocol
- Modbus, AN-D3
- Inclinometers per RS-485 line
- ≤ 40
- Total cable length
- ≤ 800 m
- Supply voltage
- 9…28
- Ranges by model
- ±6° / ±12° / ±24° / ±48° / ±60° / ±90°
Key manufacturer data is shown. Range, interfaces, and supplied components depend on the selected version.
Full manufacturer data (RU)Descriptions, specifications, and images: NTP Gorizont materials.Manufacturer resources (RU) ↗
